ISの取扱説明書・マニュアル [全34ページ 1.45MB]

1 .

821-7. Safety informationCorrect driving postureDrive in a good posture as follows:Sit upright and well back inthe seat. (→P. 46)Adjust the position of the seatforward or backward toensure the pedals can bereached and easilydepressed to the extentrequired....

2 .

831-7. Safety information1Before drivingCAUTIONnWhile drivinglDo not adjust the position of the driver's seat while driving.Doing so could cause the driver to lose control of the vehicle.lDo not place a cushion between the dr iver or passenger and the seat...

3 .

841-7. Safety informationSRS airbagsThe SRS airbags inflate when the vehi cle is subjected to certain types ofsevere impacts that may cause significant injury to the occupants. Theywork together with the seat belts to he lp reduce the risk of death or seri...

4 .

851-7. Safety information1Before drivingAirbag system componentsYour vehicle is equipped with AD VANCED AIRBAGS designed basedon US motor vehicle safety standards (FMVSS208). The airbag systemcontrols airbag deployment power for the driver and front passe...

5 .

861-7. Safety informationIn certain types of severe frontal or side impacts, the SRS airbag systemtriggers the airbag inflators. A chemica l reaction in the inflators quicklyfills the airbags with non-toxic gas to he lp restrain the motion of the occu-pan...

6 .

871-7. Safety information1Before drivingnOperating conditions (side and curtain shield airbags)lThe SRS side airbags and curtain shield ai rbags are designed to inflate when thepassenger compartment is subjected to a severe impact from the side.lThe SRS si...

7 .

881-7. Safety informationnTypes of collisions that may not deploy the SRS airbag (side and curtain shield airbags)The SRS side airbag and curtain shield ai rbag system may not activate if the vehicleis subjected to a collision from the side at certain angl...

8 .

891-7. Safety information1Before drivingnWhen to contact your Lexus dealerIn the following cases, contact your Lexus dealer as soon as possible. Do not dis-connect the battery cables before contacting your Lexus dealer.lAny of the SRS airbags have been inf...

9 .

901-7. Safety informationCAUTIONnSRS airbag precautionsObserve the following precauti ons regarding the airbags. Failure to do so may cause death or serious injury.lThe driver and all passengers in the vehicle must wear their seat belts properly.The SRS ai...

10 .

911-7. Safety information1Before drivingCAUTIONnSRS airbag precautionslThe SRS front passenger airbag also depl oys with considerable force, and cancause death or serious injury especially if the front passenger is very close to theairbag. The front passe...

11 .

921-7. Safety informationCAUTIONnSRS airbag precautionslDo not sit on the edge of the seat or leanagainst the dashboard.lDo not allow a child to stand in front of theSRS front passenger airbag unit or sit onthe knees of a front passenger.lDo not drive the ...

12 .

931-7. Safety information1Before drivingCAUTIONnSRS airbag precautionslIf the vinyl cover is put on the area where the SRS knee airbag will deploys, besure to remove it.lDo not use seat accessories which cove r the parts where the SRS side airbagsinflate a...

13 .

941-7. Safety informationCAUTIONnModification and disposal of SRS airbag system componentsDo not dispose of your vehicle or perfor m any of the following modifications with-out consulting your Lexus dealer. The SRS airbag may malfunct ion or deploy (inflat...

14 .

9511-7. Safety informationBefore drivingFront passenger occupant classification systemYour vehicle is equipped with a front passenger occupant classification sys-tem. This system detects the conditions of the front passenger seat andactivates or deactivat...

15 .

961-7. Safety informationCondition and operation in the front passenger occupant classification systemnAdult*1nChild *3 or child restraint system*4Indicator/warning light"AIR BAG ON" and "AIR BAG OFF" indicator lights"AIR BAG ON"SRS warning light OffFront ...

16 .

971-7. Safety information1Before drivingnUnoccupiednThere is a malfunction in the system*1: The system judges a person of adul t size as an adult. When a smalleradult sits in the front passenger se at, the system may recognize him/her as a child depending ...

17 .

981-7. Safety information*4: Never install a rear-facing child re straint system on the front passen-ger seat. A forward-facing child restraint system should only beinstalled on the front passenger se at when it is unavoidable. (→P.100)*5: In case the ind...

18 .

991-7. Safety information1Before drivingCAUTIONnFront passenger occupant classi fication system precautionslDo not recline the front passenger seatback so far that it touches a rear seat. Thismay cause the "AIR BAG OFF" indicator ligh t to be illuminated, ...

19 .

1001-7. Safety informationChild restraint systemsPoints to rememberStudies have shown that installing a ch ild restraint on a rear seat is muchsafer than installing one to the front passenger seat. lChoose a child restraint system that suits your vehicle ...

20 .

1011-7. Safety information1Before drivingForward facing ⎯ Convertible seatBooster seatnSelecting an appropriate child restraint systemlUse a child restraint system appropriate for the child until the child becomeslarge enough to properly wear the vehicle's...

21 .

1021-7. Safety informationCAUTIONnChild restraint precautionslLexus strongly urges the use of a proper child restraint system that conforms tothe size of the child, installed on the rear seat. According to accident statistics, thechild is safer when prope...

22 .

1031-7. Safety information1Before drivingCAUTIONnChild restraint lock function belt precautionDo not allow children to play with the child restraint lock function belt. If the beltbecomes twisted around a child's neck, it will not be possible to pull the ...

23 .

1041-7. Safety informationInstalling child restraintsFollow the child restraint system ma nufacturer's instructions. Firmlysecure child restraints to the rear seats using the LATCH anchors or a seatbelt. Attach the top tether strap when installing a chil...

24 .

1051-7. Safety information1Before drivingInstallation with LATCH systemType AFlip the cover.Latch the hooks of thelower straps onto theLATCH anchors. If the child restraint has atop tether strap, the toptether strap should belatched onto the top tetherstra...

25 .

1061-7. Safety informationType BFlip the cover.Latch the buckles onto theLATCH anchors. If the child restraint has atop tether strap, the toptether strap should belatched onto the top tetherstrap anchors. For owners in Canada:The symbol on a child restrain...

26 .

1071-7. Safety information1Before drivingInstalling child restraints using a seat belt (child restraint lock function belt)nRear facing ⎯ Infant seat/convertible seatPlace the child seat on the rearseat facing the rear of the vehicle.Run the seat belt thro...

27 .

1081-7. Safety informationWhile pushing the child seat downinto the rear seat, allow the shoul-der belt to retract until the childseat is securely in place.After the shoulder belt hasretracted to a point where there isno slack in the belt, pull the belt to...

28 .

1091-7. Safety information1Before drivingWhile pushing the child seat intothe rear seat, allow the shoulderbelt to retract until the child seat issecurely in place.After the shoulder belt hasretracted to a point where there isno slack in the belt, pull the...

29 .

1101-7. Safety informationRemoving a child restraint installed with a seat beltPush the buckle release buttonand fully retract the seat belt. Child restraint systems with a top tether strapSecure the child restraint using aseat belt or a lower anchors, and...

30 .

1111-7. Safety information1Before drivingnLaws and regulations pertaining to anchoragesThe LATCH system conforms to FMVSS225 or CMVSS210.2.Child restraint systems conforming to FMVSS213 or CMVSS213 specificationscan be used.This vehicle is designed to conf...

31 .

1121-7. Safety informationCAUTIONnWhen installing a child restraint systemFollow the directions given in the child restraint system installation manual and fixthe child restraint system securely in place.If the child restraint system is not correctl y fixe...

32 .

1131-7. Safety information1Before drivingCAUTIONnDo not use a seat belt extenderIf a seat belt extender is used when inst alling a child restraint system, the seat beltwill not securely hold the child restraint system, which could cause death or seriousin...

33 .

1141-7. Safety information

34 .

1151-7. Safety information1Before driving
